Model | R006 | ||
Battery type | Li ion Battery | ||
Rated Voltage | 36V | ||
Rated Capacity | 17.5Ah | ||
Battery cell | 18650 3500mAh cells | ||
Dimension(mm) | 440*155*60 | ||
Battery weight | 6.8KG | ||
BMS current | 20A, fit for 500w motor | ||
Max.charge current | 3A | ||
Charge voltage | 42v | ||
Discharge cut-off voltage | 28v | ||
Charger | 42V 2A | ||
Corlor |
black |
Voltage |
36V, 48V |
---|---|
Current |
12Ah, 13Ah, 15Ah, 17.5Ah |
BMS |
BMS20A, BMS30A |
Battery Cells |
Chinese 2500mAh cells, Chinese 3000mAh cells, Chinese 3500mAh cells |
Charger |
2A Charger |
with/without Rack |
with Rack, without Rack |
